AUTOMATIC BAR SCREEN

Waste water that can come to the system from sewerage or waste water collectors passes through a coarse screen with a screen spacing of 30-50 mm. Coarse screens can be controlled automatically or manually from the local panel.

Manual operation: The operator can perform the cleaning of the grill at any time and in certain periods.

Automatic operation: It can be controlled in two different ways depending on the level sensors and depending on the time setting. Coarse Grids as production; The main chassis material is ST37 epoxy paint coated and the main chassis material is AISI 304 or AISI 316. Grids and rakes are produced from AISI 304 material.

Grid System; It is a physical treatment method used in wastewater treatment plants, which is used at the entrance of the plant and designed to remove coarse solids that may damage the installations and equipment of the treatment plant that may be present in the wastewater. The most commonly used screen models in large and medium-sized treatment plants are both fine and coarse screens.

They can work even in very deep channels, depending on the need, without limitation of channel height. Linear mechanical screen is a mechanical equipment that cleans the bar screen mounted at 75˚ angle to the channel bottom by scanning vertically. It is generally composed of chassis, fixed grid, stripping system. All movements of the scraper pallets are automatically controlled. The scraping movement, which starts from the bottom dead center, ends when the scraper at the top dead center transfers the garbage accumulated in the comb to the collection container. At the moment of descent, the comb changes its position and moves away from the grid.
